MOZA Racing R5 Bundle
MOZA Racing R5 wheel base clamped to a desk. Part of the Moza R5 Bundle.
MOZA Racing ES Steering Wheel. Part of the Moza R5 Bundle.
MOZA Racing R5 Wheel Base. Part of the Moza R5 Bundle.
MOZA Racing SR-P lite pedals. Part of the Moza R5 Bundle.

MOZA RACING R5 Bundle Kit

£459.00
Regular price
Split your purchases into 3 interest-free payments.
£459.00  inc. vat

MOZA RACING R5 Bundle Kit

£459.00

Total £459.00

Shop & Sustain: Make a better tomorrow

×
Klarna Logo.

Pay in 3 with Klarna

Close

Klarna's Pay in 3 / Pay in 30 days are unregulated credit agreements. Borrowing more than you can afford or paying late may negatively impact your financial status and ability to obtain credit. 18+, UK residents only. Subject to status. Ts&Cs and late fees apply.

Free delivery on all orders over £70
RETURN GUARANTEE Within 14 days
10+ YEARS OF EXPERIENCE Since 2009

Get behind the wheel in style with the MOZA Racing R5 bundle. This comprehensive bundle includes a steering wheel, wheelbase, pedal set and even a table clamp - everything you need to experience the MOZA ecosystem and take your racing to the next level.

For pure performance to the £ spent, this bundle is second to none. The high-quality equipment is easy to install and is packed with features to allow you to tailor your racing setup to your needs.

Looking to fine tune your outputs when racing? This bundle is fully supported by the MOZA Pit House software which allows you to make precision adjustments to get the most out of your wheel and pedals.

R5 Direct Drive Wheelbase

Designed and engineered with the help of motorsport experts, the MOZA R5 Direct Drive Wheelbase packs a punch!

Maximum power with minimum volume, the R5 delivers 5.5 N⋅m of torque giving you a responsive, rewarding and fluid racing experience. Steering is managed through an ultra-high resolution 15-bit motor encoder, providing you with incredibly accurate steering and an unlimited steering angle.

As well as offering a huge range of functionality, the R5 wheelbase is built to last and is reliable throughout even the longest endurance races. The aviation grade aluminium casing is incredibly durable and houses an intelligent temperature control system which keeps all the important components cool and protected. The base and the steering wheel are connected through a military-grade conductive slip ring with a life of 5 million revolutions. This unique patented design feature grants extremely high stability and durability while still allowing for high-speed rotation.

ES Steering Wheel

The MOZA Racing ES Steering wheel is only available as part of the R5 bundle and is designed to maximise the cost to performance of this affordable sim racing bundle.

Lightweight, customisable and durable, the ES steering wheel features specially selected materials such as microfiber leather grips and a sleek aluminium alloy frame. Enjoy complete control at your fingertips with 22 fully programmable buttons alongside MOZA’s signature flow light design to ensure every shift is just right. This budget friendly steering wheel consistently delivers a reliable and comfortable sim racing experience tailored to your own requirements.

As with all MOZA Wheels, the ES Steering Wheel features a quick release mechanism that allows you to easily attach or detach the wheel from any MOZA Racing Wheelbase in seconds.

SR-P Lite Pedal Set

The MOZA Racing SR-P Lite Pedal set is a 2 Pedal Set featuring both the accelerator and brake pedal.

Built with longevity in mind, the pedal set is manufactured with high-strength steel to provide rock-solid durability for even the most aggressive drivers. Each pedal is fitted with a precise Hall sensor to give you fine control over your footwork when driving, ensuring maximum consistency and performance.

To find your optimal racing position the pedals can be easily spaced and configured for maximum comfort and accessibility. Whether racers want to mount their pedals inverted or have other ideas, our detachable design allows for home setups of professional simulator designs.

R5 Table Clamp

Don’t have space for a wheel stand or racing simulator? The MOZA Racing R5 bundle comes with a handy steering wheel table clamp letting you enjoy the thrill of racing with limited space.

The R5 table clamp is constructed with 5mm thick steel and features two highly adjustable brackets to help you lock your wheel firmly in position for a reliable and remarkable racing experience.

Read more...
  • 5.5 N⋅m of Torque from Direct Drive Power
  • Aircraft Grade Aluminium / Hand-Made stitched leather / High - Strength Steel
  • Ultra-high Power Density Servo Motor
  • Customised quick release function
  • 22 Programmable Buttons
  • Adjustable Spacing and Height
  • Mapping Pedal Output curves
  • MOZA Pit House Control Software
  • App Cloud Control
Dimension
×

R5 Direct Drive Wheelbase

Designed and engineered with the help of motorsport experts. Maximum power with minimum volume, the R5 delivers a punchy 5.5 N⋅m of torque giving you a responsive, rewarding and fluid racing experience.

MOZA - R5 Bundle Kit
MOZA - R5 Bundle Kit

ES Steering Wheel

Lightweight, customisable and durable, the ES steering wheel features specially selected materials such as microfiber leather grips and a sleek aluminium alloy frame along with 22 fully customisable buttons.

SR-P Lite Pedals

Manufactured with high-strength steel to provide rock-solid durability and fitted with precise Hall sensors to give you fine control over your footwork when driving, ensuring maximum consistency and performance.

MOZA - R5 Bundle Kit
MOZA - R5 Bundle Kit

R5 Table Clamp

Perfect for people racing at a desk, the R5 table clamp is constructed with 5mm thick steel and features two highly adjustable brackets to help you lock your wheel firmly in position for a reliable and remarkable racing experience.

  • MOZA DD R5 Wheelbase x1
  • ES Steering Wheel x1
  • SR-P Lite Pedals (No Clutch) x1
  • R5 Table Clamp x1
  • 15 Degree Desktop Mounting Clip
  • 15 Degree Desktop Mounting Clip
  • Power Supply
  • Power Cable
  • USB Cable
  • M4*10 Socket Screws x12
  • M6*20 Socket Head Screws x2
  • M8 Nuts x3
  • M6x12 Socket Head Screws x4
  • Pedal Fixed Rubber Columns x2
  • 2.5mm Hexagonal Wrench x1
  • 7mm Open End Wrench x1
  • 5mm Hexagonal Wrench
  • Type A to Type B USB Cable x1
  • M8*12 Hexagonal Screws x3

Q - Is this a good bundle for sim racing beginners or people new to wheels and pedals?

A - The MOZA racing R5 bundle is the perfect first step for people stepping into the wonderful world of sim racing. Enjoy a complete sim racing eco system at less than half the price of some wheelbases on the market.

Q - Is the MOZA R5 bundle easy to set up?

A - The included steering wheel, pedals and table clamp lets you simply plug in and play. Start racing straight away without any other peripherals.

Q - Is there a recommended GT Omega Product for the R5 bundle?

A - The R5 bundle is compatible with all GT Omega wheel stand and sim racing cockpits. Our recommendation for people making the jump to a full sim racing setup is to begin with our Classic Steering Wheel Stand or Apex Steering Wheel Stand as these are compact and functional and can be upgraded to a full racing cockpit down the line.

Q - Is it possible to mount the MOZA Racing R5 wheelbase to a desk?

A - The MOZA R5 bundle comes packed with a table clamp which makes it easy to mount to any desk or table.

Q - Is the MOZA R5 bundle compatible with gaming consoles?

A - The Moza R5 bundles is currently not able to be used with consoles such as the Playstation 4, Playstation 5, Xbox One or Xbox Series X/S. However this may change in the future…

Q - Is the MOZA R5 bundle worth it?

A - Yes, absolutely. The MOZA R5 bundle is a comprehensive sim racing package at an affordable price and delivers an amazing racing experience straight out of the box. This is currently the cheapest direct drive bundle available today.

R5 Wheelbase

Case Material
Aviation Grade Aluminium
Cooling Type
Passive
Platform
PC (Windows)
Drive Form
Direct Drive
Steering Angle
Unlimited
Maximum Torque
5.5 N⋅m
Maximum Power
95W
Input Voltage
110V~220V AC | 12V DC
USB Refresh Rate
1000Hz
Quick Release
D1 Compatible
Connection Port
Starting Switch, Power Supply. Data, Display screen
Mounting
4 Holes on base. Exclusive Holder that supports angle adjustment and side fix; table clamp
Size
156.8mm x 73.9mm x 124mm (L x W x H)

ES Steering Wheel

Wheel Material
Microfiber Leather
Frame and Front Plate material
Aluminium Alloy
Dial Material
Aluminium Alloy
Size
11 Inches
Programmable Buttons
22
LED Lamp Beads
10
Intelligent Telemetry
Supported
Configurable LEDs (MOZA Pit House)
Supported
Disassembly Method
Quick Release System

SR-P Pedals

Material
High-Strength Steel
Plate material
High-Strength Steel
Colour
Black
Pedal Sensor Type
Hall Sensor
Pedal Spacing
Adjustable
Pedal Plate Height
Adjustable
Pedal Input Adjustment
Supported
Pedal Input Reversal
Supported
Pedal Output Curve Adjustment
Supported
Anti-Slip Pad
Included
