SLEEK, MODERN DESIGN
Inspired by current supercar trends, the R21 sports a robust design and a clean two-tone painted finish.
STURDY, ALUMINIUM BODY
The MOZA R21 is made of aluminium alloy, giving the base a rock-solid feel and weight.
ULTRA LOW STATIC TORQUE
Feel everything through an optimized motor design, offering practically zero torque ripple notching or cogging.
SUPERIOR TEMPERATURE CONTROL
Enjoy reliable and steady temperature control with the MOZA R21. The R21 will never reduce output or attenuate due to overheating. Even during endurance racing.
262,144 POINTS OF RESOLUTION
The MOZA R21 encoder incorporates ultra-high precision wheel position monitoring, allowing for accurate and clear feedback when racing.
Product Details
Discover the pinnacle of the MOZA RACING sim racing wheel bases collection, the MOZA R21 V1.
The MOZA RACING R21 is the epitome of peak performance when it comes to sim racing wheel bases. Fluid feedback and a uniquely fine-tuned responsiveness ensure an unbeatable sim racing experience every time you get behind the wheel.
Featuring a remarkable peak torque of 21 N·m, it sports a 30% larger torque output than other similar models, it delivers unparalleled force feedback for a truly immersive racing experience. Its all-aluminum alloy body combines strength and elegance with its unique supercar-inspired design.
The R21 motor utilizes 6 unique design approaches to ensure a smooth racing experience. The rotor of the R21 is a triple staggered slanted pole design commonly found in electric motor vehicles and ensures a balanced vibration-free motor. Featuring 262,144 points of resolution, every movement is captured with exceptional precision. With hands-off protection and ultra-low static torque, you can focus on the race without distractions.
Take control with the MOZA Pit House App Control, allowing you to fine-tune settings with ease. Its one-click launching system puts you on the fast lane to victory.
- 21 N·M maximum torque
- Unmatched Quality and Durability
- Body Shape inspired by supercars
- 262,144 points of resolution for precision accuracy
- Supports MOZA Pit House and Smart Phone App
- Superior Temperature Control
GT Omega:
Platforms:
- PC (Compatible with Windows PC)
| General Specifications |
| Platform | PC |
| FFB Drive System | Direct Drive |
| Max Wheel Rotation | Limitless |
| Housing Material | Aviation Grade Aluminium Alloy |
| Housing Colour | Black |
| Peak Torque | 21 Nm |
| Peak Power | 480W |
| Input Voltage | 110V~220V AC -> 36V DC |
| Encoder Resolution | 262144 PPR (18-bits) |
| USB Refresh Rate | 1000Hz |
| Indicator | Yes |
| Quick Release | Supported |
| Connection Ports | Power, DC Input, E-Stop, USB (Pogo pins for RM Dash) |
| Included Extras | User Manual, Warranty Card, Power Supply, USB Cable, Toolkit |
| Mounting Method | Bottom Mount |
| Table Clamp | Optional |
| Emergency Stop | Optional |
| Dimension (L x W x H) | 327 * 170 * 130 (mm) |
| Weight | 8.9kg |
| App Functions | Supported |
| Indicator | Yes |
